BYD · manufacturer profile
The Battery-Box Premium HVS and HVM towers
Battery manufacturerIn Australia since 2016
Updated 3 November 2026 · Checked against BYD's Australian datasheet, warranty and compatible inverter list, the CEC register (16 November 2026) and Synergy's list (30 October 2026) · By Solar Battery Perth
In short
BYD makes the Battery-Box Premium, two towers of LFP modules (lithium iron phosphate), each on its own base with the top fixed to the wall, that run with another maker's inverter, chosen from BYD's own compatible list. The HVS stacks 2.56 kWh modules, two to five high, for 5.12 to 12.8 kWh usable. The HVM stacks 2.76 kWh modules, three to eight high, for 8.28 to 22.08 kWh. Up to three identical towers share one inverter. Both carry 10 years and a 70% promise on usable energy, or an energy cap, whichever comes first. Alps Power Pty Ltd in Riverwood, New South Wales, is the service partner a claim reaches. A battery system needs an inverter with a battery-storage (DER-Storage) listing on Synergy's Supported Solutions List to be eligible for the WA Battery Scheme. Other scheme conditions apply. Several inverter series on BYD's compatible list were on Synergy's list dated 30 October 2026. A Battery-Box on one of them pairs with an inverter listed for battery storage on Synergy's list.
Specifications and pricing change. Confirm them with the manufacturer.
The company
BYD was founded in February 1995 as Shenzhen BYD Battery Company Limited. It took its current name, BYD Company Limited, on 11 June 2002. It is based in Shenzhen, with its office in the city's Pingshan district. Its own filing lists four businesses: new energy vehicles, phone parts and assembly, rechargeable batteries and solar. Its shares trade in Hong Kong under the code 01211 and in Shenzhen under 002594. At 31 December 2025 it had about 869,600 employees.
In storage, BYD's filing covers utility-scale, industrial and commercial, flash charging and residential products. By its own account it delivered more than 60 GWh of storage systems in 2025. It also says it has supplied storage to more than 650 large projects in over 110 countries and regions.
In Australia, the warranty names Alps Power Pty Ltd at Riverwood in New South Wales as BYD's authorised service partner. BYD's newer Australian datasheets name BYD Australia Pty Ltd as the importer. By March 2016 Alps Power was describing itself as the official after-sales service partner for BYD storage in Australia. BYD's own B-Box warranty letter for Australia took effect on 1 January 2017. The warranty itself is given by Shenzhen BYD Electronics Co., Ltd.
A claim is reported in writing to Alps Power, as BYD's partner in Australia. If the partner cannot be contacted, it goes to BYD Global Service in Shenzhen. BYD then repairs or replaces the battery at its own discretion, or offers a partial refund.
From BYD's Australian HV warranty, read 8 October 2026.
The battery and the inverter come from different makers. Every inverter on BYD's compatible list, version 2.22, is another company's, and the list sets a minimum inverter and battery firmware for each one. It also gives each inverter its own module range. Some stop short of a full tower: one takes two to four HVS modules and no HVM, another two to three HVS and three to four HVM. So the inverter on the quote decides how tall the tower can be.
The tower grows in small steps. Each module adds 2.56 kWh on the HVS or 2.76 kWh on the HVM, so storage is sized to the home in steps of less than 3 kWh. The modules connect through a plug design with no internal wiring, and modules or whole towers can be added later. Modules bought after the first installation carry their own performance warranty, dated from their own invoice.
The warranty's capacity promise ends at an energy cap, not only at 10 years. Each tower size has its own cap in the warranty table, and the 70% promise runs until the cap or the tenth year, whichever comes first. At one full cycle a day, that cap arrives after about 8.2 years on the HVS and 8.5 on the HVM.
On the Clean Energy Council (CEC) register, the first current listing of each series dates from 8 June 2023 for the HVM and 19 October 2023 for the HVS. The LVS, Battery-Box, HVE, Battery-Box HVB, HVM+ and LVL followed between then and July 2026. The HVM rows end on 5 December 2026, so a quote naming an HVM needs a fresh check that it is still listed. Every HVS and HVM row is marked for outdoor use, and BYD's operating manual adds that the spot must not be exposed to direct sun, rain or snow. This page covers the HVS and HVM, the two series whose Australian datasheet and warranty we have read. The register also carries a BYD inverter: the Power-Box SH, from SH3K to SH6K-AU, listed under Shanwei BYD Auto Co Ltd since 10 April 2026. No document for it was read for this page, and it is not on BYD's compatible inverter list.
2 to 5 modules of 2.56 kWh, 5.12 to 12.8 kWh usable, 38 kg a module, IP55 (dust-protected and protected against water jets), on its own base with the top fixed to the wall
CEC approved
3 to 8 modules of 2.76 kWh, 8.28 to 22.08 kWh usable, 35 or 38 kg a module, IP55, on its own base with the top fixed to the wall
CEC approved
Single-phase hybrid, SH3K to SH6K-AU, on the register since April 2026; no datasheet read for this page
CEC approved
One from BYD's compatible inverter list, and no other. The Australian warranty excludes operation with any inverter the HVS and HVM compatible list leaves out. The list, version 2.22 dated 10 October 2026, names only other makers' inverters, and gives each one a minimum firmware and a module range. So the quote needs three things: the inverter code, the firmware the list asks for, and a module count inside that inverter's range.
That split also divides responsibility. BYD's warranty covers the listed battery models and nothing else. The inverter beside the tower carries its own maker's warranty, so a fault in the system can mean two claims to two companies. A home that already has an inverter on BYD's list can stand a tower beside it. In WA, adding a battery to an existing solar system counts as an alteration and can trigger whole-of-site compliance, so compare an AC-coupled retrofit against replacing your inverter with a hybrid. For many existing systems the sound path is replacing toward a DC-coupled / hybrid-inverter setup rather than expanding an AC-coupled one, avoiding future compliance limitations.
Both towers use LFP cells, which the datasheet describes as cobalt-free. The enclosure is rated IP55. No BYD datasheet or manual we read describes a fire suppression module, a fire test or a cell-level safety design, so this page prints none. No BYD battery was suspended or de-listed on the CEC's tables when we read them. The one BYD entry there is from 3 September 2024, when every BYD solar panel model was de-listed because the maker had no active importer for panels in Australia.
BYD's Australian warranty for the HV (high-voltage) range covers the HVS 5.1 to 12.8 and the HVM 8.3 to 22.1, bought and installed in Australia on or after 1 November 2024. It runs 10 years against defects from the sale date on the seller's invoice. It goes to the original buyer and to any later owner who can show proof of ownership. Ten years is also the term the federal energy department says many battery makers offer.
The capacity promise is 70% of usable energy for 10 years, or until the battery reaches its minimum throughput, whichever comes first. The cap runs from 15.41 MWh (megawatt-hours) on the HVS 5.1 to 38.53 MWh on the HVS 12.8. On the HVM it runs from 25.62 MWh on the 8.3 to 68.31 MWh on the 22.1. That is about 3.0 MWh for each usable kWh on the HVS and 3.1 on the HVM. A battery emptied and refilled once a day reaches it in about 8.2 to 8.5 years, so for that home the 70% promise ends before the tenth year. At the end of the promise an HVM 22.1 still holds 15.46 kWh.
Five conditions matter most. The battery is installed within one month of its invoice date. It is never left unused for six months or more. It runs with an inverter on BYD's compatible list. Defects from temperatures above 50 °C or below -10 °C are excluded. And after a claim, BYD or its partner must be given internet access to the battery's performance data on request, or the cover is lost.
A defect is reported within 30 days of the owner becoming aware of it, in writing, to Alps Power. If the partner cannot be reached, the report goes to BYD Global Service in Shenzhen. BYD repairs or replaces at its sole discretion, or pays a partial refund. For a battery that can no longer run, the refund falls by one 120th of the maximum claim for every month since the warranty started. An inspection that finds no defect, or a cause the warranty excludes, may be invoiced to the owner. The warranty sits alongside your rights under the Australian Consumer Law.
Adding to a tower later has its own clock. Modules bought after the first installation carry the performance warranty from their own invoice date, not from the day the first tower went in.
The warranty answer is 10 years at 70% or better, or the energy cap, whichever comes first. At one full cycle a day the cap arrives in about 8.2 years on the HVS and 8.5 on the HVM, which is about 3,010 to 3,094 full cycles. The datasheet we read gives no laboratory cycle rating.
Showing: Western Australia, Synergy network. Other states: not covered yet
A battery system needs an inverter with a battery-storage (DER-Storage) listing on Synergy's Supported Solutions List to be eligible for the WA Battery Scheme. Other scheme conditions apply. Several inverter series on BYD's compatible list were on Synergy's list dated 30 October 2026. A Battery-Box on one of them pairs with an inverter listed for battery storage on Synergy's list.
Synergy's list names inverters, not batteries. A Battery-Box counts through the inverter beside it, and that inverter is another maker's, chosen from BYD's compatible list. When we read Synergy's list, several inverter series on BYD's list were on it and flagged for the WA Residential Battery Scheme. The list goes model by model, so the exact inverter code on the quote is the one that counts. Our inverter library badges each model Synergy lists for the scheme. The module count also has to sit inside that inverter's range on BYD's list.
The WA scheme also asks the household to join a virtual power plant (VPP). That is a program that lets a retailer call on a group of home batteries. Synergy's own VPP is Battery Rewards. The scheme also allows a VPP run by the battery supplier. No BYD document we read names a VPP its batteries join in WA, so that is a question for the installer. The warranty's data-access clause is separate: it is about BYD reading the battery's own records after a claim.
For a Battery-Box quote, our WA battery rebate page sets out the scheme's other conditions. Our Synergy approved products guide shows how to read the inverter list.
A BYD battery is a Battery-Box Premium tower beside another maker's inverter, with the pairing, the firmware and the module count read off BYD's own list. The HVS starts smaller and the HVM goes to 22.08 kWh, and either can be added to later, with the new modules on their own warranty clock. The 70% promise ends at an energy cap, which a daily-cycled home reaches in about 8.2 to 8.5 years. A battery system needs an inverter with a battery-storage (DER-Storage) listing on Synergy's Supported Solutions List to be eligible for the WA Battery Scheme. Other scheme conditions apply. Several inverter series on BYD's compatible list were on Synergy's list dated 30 October 2026. A Battery-Box on one of them pairs with an inverter listed for battery storage on Synergy's list.
Ask for the tower, its module count and the inverter, each by model code. Ask the installer to show the inverter and its firmware on BYD's compatible list. On the CEC register the HVM rows end on 5 December 2026. Ask for the install to happen within a month of the invoice, because the warranty depends on it.
Solar Battery Perth is independent. We're not owned by an energy retailer or a manufacturer. Installers quote the actual price.
For checking
| Warranty | 10 years against defects, and 70% of usable energy for 10 years or until the energy capBYD's Australian HV warranty |
|---|---|
| Batteries | LFP (lithium iron phosphate), 4-29.7 kWh usable |
| Approved now | 45 batteries and 5 inverters on the CEC (Clean Energy Council) register |
| Support in Australia | Office and phone line. Contact details |
| Local support | Yes, support handled through Australian channelsSource: Australian warranty, checked 8 Oct 2026Confirmed |
| CEC listings | 50 approved right now · 20 delistedApproved |
| Documents |
Each product type at a glance. The full lists, grouped by series, are below.
We haven't reviewed BYD panels in depth yet. We don't hold warranty terms or a series review for them, so confirm those with your installer. Compare panels from other brands
Pick a type to open its full list, grouped by series.
Grouped by series. Open a series for each variant, or a model for full specs.
45 CEC-approved batteries · grouped into 8 series
HVE 10.7
HVE 12.8-1
HVE 12.8-2
HVE 15.0
HVE 17.1-1
HVE 17.1-2
HVE 19.2
HVE 19.3
HVE 21.4
HVE 23.5
HVE 6.4
HVE 8.5
Based on manufacturer specifications and CEC-approved configurations. Always confirm system design with your installer.
Grouped by series. Open a series for each variant, or a model for full specs.
5 CEC-approved inverters · grouped into 5 series
Compatible batteries: HVS 5.1, HVS 7.7, HVS 10.2, HVS 12.8, HVM 13.8, HVM 16.6, HVM 19.3
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 3.11/3.11 | 3.11/3.11 | 3.11/3.11 | 3.11/3.11 | 3.11/3.11 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 3.81/3.81 | 3.81/3.81 | 3.81/3.81 | 3.81/3.81 | 3.81/3.81 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.14/4.14 | 4.14/4.14 | 4.14/4.14 | 4.14/4.14 | 4.14/4.14 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 4.75/4.75 | 4.51/4.51 | 4.75/4.75 | 4.75/4.75 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 5.17/5.17 | 4.51/4.51 | 5.17/5.17 | 5.17/5.17 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.2/6.2 | 4.51/4.51 | 5.63/5.63 | 6.2/6.2 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.76/6.76 | 4.51/4.51 | 5.63/5.63 | 6.76/6.76 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.76/6.76 | 4.51/4.51 | 5.63/5.63 | 6.76/6.76 |
Compatible batteries: HVS 5.1, HVS 7.7, HVS 10.2, HVS 12.8, HVM 13.8, HVM 16.6, HVM 19.3
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 2.56/2.56 | 3.15/3.15 | 3.15/3.15 | 3.15/3.15 | 2.56/2.56 | 3.15/3.15 | 3.15/3.15 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 2.56/2.56 | 3.84/3.84 | 4.18/4.18 | 4.18/4.18 | 2.56/2.56 | 3.2/3.2 | 3.84/3.84 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 2.56/2.56 | 3.84/3.84 | 5.2/5.2 | 5.2/5.2 | 2.56/2.56 | 3.2/3.2 | 3.84/3.84 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.22/6.22 | 6.22/6.22 | 6.22/6.22 | 4.51/4.51 | 5.63/5.63 | 6.22/6.22 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.76/6.76 | 8.26/8.26 | 8.26/8.26 | 4.51/4.51 | 5.63/5.63 | 6.76/6.76 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.76/6.76 | 9.01/9.01 | 10.3/10.3 | 4.51/4.51 | 5.63/5.63 | 6.76/6.76 |
| Battery Model | HVS 5.1 | HVS 7.7 | HVS 10.2 | HVS 12.8 | HVM 13.8 | HVM 16.6 | HVM 19.3 |
|---|---|---|---|---|---|---|---|
| Charge/Discharge (kW) | 4.51/4.51 | 6.76/6.76 | 9.01/9.01 | 11.26/11.26 | 4.51/4.51 | 5.63/5.63 | 6.76/6.76 |
Understanding Power Ratings:
* DC charge/discharge power varies from AC power due to inverter efficiency. Always consult with your installer for specific system design.
Grouped by series. Open a series for each variant, or a model for full specs.
0 CEC-approved panels, 20 not currently listed
BYD370MGK-30
BYD375MGK-30
BYD380MGK-30
BYD405MLK-27
BYD410MLK-27
BYD415MLK-27
BYD445MGTK-36
BYD450MGK-36
BYD450MGTK-36
BYD455MGK-36
BYD455MGTK-36
BYD460MGTK-36
BYD490MLK-33
BYD495MLK-33
BYD500MLK-33
BYD535MLK-36
BYD535MLTK-36
BYD540MLK-36
BYD540MLTK-36
BYD545MLTK-36
What has happened to BYD on the CEC register.
Each block is one register event. Tap a year to see its events in the list below.
BYD Australia Energy ABN Registered
Chinese EV and battery manufacturer establishes Australian energy division
Only the ones on BYD's compatible inverter list, version 2.22. Every inverter on it is from another maker, and the list sets a minimum firmware and a module range for each. The Australian warranty excludes any inverter the list leaves out.
The warranty promises 70% of usable energy for 10 years or until an energy cap, whichever comes first. At one full cycle a day the cap arrives in about 8.2 years on the HVS and 8.5 on the HVM.
Yes. The modules plug together with no internal wiring, an HVS takes up to five and an HVM up to eight, and up to three identical towers share one inverter. Modules bought later carry their own performance warranty from their own invoice date, and the inverter's module range on BYD's list still applies.
Yes, on the manual's conditions. The datasheet rates both towers IP55 for -10 to +50 °C, and every HVS and HVM row on the CEC register is marked for outdoor use. BYD's operating manual says the spot must not be exposed to direct sun, rain or snow, and it shows an install under the eaves as acceptable. The warranty does not cover defects from an install that doesn't follow the manual, and it excludes defects from temperatures above 50 °C.
Not day to day, by the documents we read. After a claim, though, BYD or Alps Power must be given internet access to the battery's performance data on request, or the warranty is lost.
Alps Power Pty Ltd at Riverwood in New South Wales, BYD's authorised service partner. A claim goes to it in writing within 30 days of the defect being noticed. If Alps Power cannot be reached, it goes to BYD Global Service in Shenzhen.
BYD is headquartered in Shenzhen, China and was founded in 1995. Its products are sold in Australia through SAA-accredited installers.
Yes. BYD entered the Australian market in 2016, and its products are installed across Perth and Western Australia by SAA-accredited installers. Confirm local support and warranty handling with your installer before you buy.
