Back to all batteries

CEC approved: June 2024Report outdated info

Deye RW-F10.2

Name: Deye RW-F10.2
Brand: Deye

RW series

CEC Approved

View datasheet (PDF)

Part of RW — see all configurations

Usable capacity: 9.2 kWh
Continuous power: 6 kW
Peak power: 12 kW
Round-trip efficiency: 90%
Warranty: 10 yr
Chemistry: LiFePO4

Full specifications

Parsed from the manufacturer datasheet, install manual, and warranty document. Confirm against the linked PDFs before relying on a value for a quote or installation.

Cell & chemistry

Chemistry: LiFePO4
Cell type: Lithium Iron Phosphate

Capacity & power

Nominal capacity: 10.2 kWh
Usable capacity: 9.2 kWh
Continuous power: 6 kW
Peak power: 12 kW
Depth of discharge: 90%
Round-trip efficiency: 90%
Nominal voltage: 51.2 V

Lifespan & degradation

Cycle life: 6000 cycles
Capacity retained at year 10: 70%
Warranted throughput: 32 MWh

Modularity & stacking

Modular / stackable: Yes
Maximum stack: 326 kWh

Backup & grid services

Backup capable: No
VPP ready: Yes

Physical

Dimensions (H×W×D): 760 × 600 × 200 mm
Weight: 104 kg
IP rating: IP65

Operating environment

Operating temperature: -20°C to 55°C

Resources

Datasheet Warranty terms Installation guide

Warranty and support

Warranty terms and Australian support structure.

The warranty covers defects in materials and craftsmanship for 10 years, ensuring at least 70% capacity retention. Claims must be made within specified periods. Restrictions may apply based on installation practices.

Duration

years

Throughput

MWh

Max Temp

55°

celsius

Max Backup

Level 0

No Backup

Australian support structure

Not verified

We have not verified this brand's Australian support structure. Confirm warranty arrangements with the manufacturer or your installer.

Perth climate suitability

Suited to Perth climate

Rated to 55°C, which covers Perth's hottest days.

Key warranty terms

•Depth of Discharge: 90% usable capacity
•Round-trip Efficiency: 90% rated
•Annual Degradation: ~2.5% per year expected
•Installation: Must be installed by SAA-accredited installer
•Operating Conditions: -20°C to 55°C

✗ Non-transferableFull replacement≥70% capacity at year 10

Warranty Document Datasheet Compare Warranties

WA Battery Scheme eligibility

Likely eligible

Synergy SSL inverter pairing, VPP participation and state-rebate qualification for this battery. Rebate and STC amounts are shown in the pricing panel.

CSIP-AUS compliant
Inverter must be CSIP-AUS compliant under the current WA framework.
Synergy SSL approved inverter
Pairs with NINGBO DEYE INVERTER TECHNOLOGY CO LTD HYBRID INVERTER.
VPP activation ready
Ready for Synergy VPP participation.
WA Battery Scheme rebate
Up to $1,300 for Synergy customers (10kWh max eligible).
Synergy Battery Rewards
Requires a CSIP-AUS compliant system and reliable internet.
Interest-free loan
Qualifies for up to $10,000 interest-free.

Under current WA rules, new rebate applications require VPP enrolment and CSIP-AUS compliance. How the scheme works · Estimate VPP earnings

About Deye

View Full Profile →

Years in AU Market6+ years

Local SupportNot verified

CEC-Listed Products53 models

6yr AU

CEC-approved products since 2020

6 years in the Australian market

Fault & error codes — Deye RW

Extracted from the installation manual

7 documented

Showing 7 of 7. The official install manual is the authoritative source — always confirm before acting.

BMS faultcriticalCall your installer
Manual (PDF)
Battery Management System fault
Likely cause
The cell voltage sampling circuit is faulty; the cell temperature sampling circuit is faulty.
What to do
Replace the battery.
Electrochemical cell faultcriticalCall your installer
Manual (PDF)
Cell voltage is low or unbalanced
Likely cause
Due to large self-discharge, the cell over discharges to below 2.0V after long term storage; the cell is damaged by external factors, and short circuits, pinpricks, or crushing occur.
What to do
Replace the battery.
Charge low temperature protectionwarningCall your installer
Manual (PDF)
Battery is too cold to operate
Likely cause
The battery ambient temperature is too low.
What to do
Contact local engineers to rectify the fault.
Charge or discharge high temperature protectionwarningCall your installer
Manual (PDF)
Battery is overheating
Likely cause
The battery ambient temperature is too high; there are abnormal heat sources around.
What to do
Contact local engineers to rectify the fault.
Discharge low temperature protectionwarningCall your installer
Manual (PDF)
Battery is too cold to discharge
Likely cause
The battery ambient temperature is too low.
What to do
Contact local engineers to rectify the fault.
Overvoltage protectionwarningCall your installer
Manual (PDF)
Battery voltage exceeds normal limits
Likely cause
The busbar input voltage exceeds the normal value; cells are not consistent; the capacity of some cells deteriorates too fast or the internal resistance of some cells is too high.
What to do
If the battery cannot be recovered, contact local engineers to rectify the fault.
Under voltage protectionwarningCall your installer
Manual (PDF)
Battery voltage is below acceptable levels
Likely cause
The mains power failure has lasted for a long time; cells are not consistent; the capacity of some cells deteriorates too fast or the internal resistance of some cells is too high.
What to do
Contact local engineers to rectify the fault.

Perth pricing

Typical installed price

$8,740

WA State Rebate-$1,196

Federal STCs-$2,474

After Rebates~$5,070

Prices are estimates. Final pricing depends on installation requirements. STC value is based on the current certificate price of about $39.9.

Explore your options

Insufficient Data for Scoring

3 of 5 critical specs available (need 4)

Part of the Deye RW

See all configurations in this series →

Compare options

Compare this battery with other models to find the best fit for your needs.

Compare Products

Frequently asked questions

How it compares

The Deye RW-F10.2 against the closest-sized batteries from other brands.

Specification	Deye RW-F10.2Deye	AVOL Genius BA10AVOL	Hiconics HEC-S B 10KHiconics

Usable capacity?	9.2 kWh	9.2 kWh	9.2 kWh
Continuous power?	6 kW	Not verified	Not verified
Peak power?	12 kW	Not verified	Not verified

Round-trip efficiency?	90%	92%best value	92%best value
Warranty	10 years	10 years	10 years
Chemistry	LiFePO4	LFP	LFP

Specs from the CEC register and datasheet enrichment. Indicative — confirm exact figures with your installer.
